Autel Anti Fpv C-Uas Mavic 3 Autel Fpv Ua Poland RF Module 700-1000MHz 50W GaN Anti-Module

Name: Autel Anti Fpv CUas Mavic 3 Autel Fpv Ua Poland RF Module 7001000MHz 50W GaN AntiModule
Brand: LDSK
Price: 1 USD

Wholesale Autel Anti Fpv C-Uas Mavic 3 Autel Fpv Ua Poland RF Module 700-1000MHz 50W GaN Anti-Module from china suppliers

Place of Origin : Guangdong, China

Brand Name : LDSK

MOQ : 1 piece

Delivery Time : 1-3 workdays

Payment Terms : D/A, D/P, T/T, Western Union, MoneyGram， Paypal

Supply Ability : 50000 pcs per month

Model NO. : LDSK

Usage : 24-32V

Frequency : 700-1000MHz

out Power : 50W

Product Weight : 160g

Product Size : 37.3*112*19.5mm

Connect Line : Red:DC24-32V Black:Gnd White:Enable

Transport Package : Carton

Specification : 20X30X10 cm

Trademark : LDSK

Origin : Guangdong, China

Package Size : 20.00cm * 2.00cm * 10.00cm

Package Gross Weight : 2.000kg

Gain : 47dBm

Samples : US$ 135/Piece 1 Piece(Min.Order) |

Customization : Available | Customized Request

Contact Now

Product Parameters

--GaN enables high efficiency and high output. The radio frequency and monitoring technical indicators of the power amplifier module stipulate the definition of each port of the module and the shape and structure of the module.

--The power amplifier uses domestic core key components and can operate normally at temperatures of -10~+55°C.

--This document stipulates the radio frequency and monitoring technical indicators of the 700-1000MHz 50W power amplifier module, the definition of each port of the module, the appearance and structure of the module, etc.

--This document applies to all aspects of product design, verification, production and quality inspection of the 700-1000MHz 50W power amplifier module.

Item name	Technical parameters
Working frequency	700-1000MHz
Power	50W
Supply Voltage	DC 24-32V
Max Output Power	47 dBm
Working Efficiency	≥60%
Passband Riplpe	≤2dB
Weight	105 g
Operating Temperature	-10~+55ºC
Power supply requirements	≥3.7A
RF Connector	SMA
Weight	160g
Size	37.311219.5mm (Excluding SMA)
Connect line red	DC28-30V
Connect line black	GND
Connect line white	ENABLE

Product Description

Autel Anti Fpv C-Uas Mavic 3 Autel Fpv Ua Poland RF Module 700-1000MHz 50W GaN Anti-Module

Lead time

Quantity(PCS)	<100pcs	<500	500-1000	>1000
Lead time(Days)	3	3-5	7-12	To be negotiated

Customization

Item	Logo	Frequency	Power	Packing
MOQ(PCS)	1	1	1	1

Company profile

Autel Anti Fpv C-Uas Mavic 3 Autel Fpv Ua Poland RF Module 700-1000MHz 50W GaN Anti-Module

Shenzhen ladasky technology Co,.LTD, specializing in the field of advanced technology. Our company is located in the vibrant city of Shenzhen, known as a hub of innovation and technology in China.

Our main products include RF module and anti FPV, which are designed with cutting-edge technology and strict quality control to meet the diverse needs of our customers. The RF module offers high-performance and stable signal transmission, enabling seamless communication in various applications. The anti FPV solution provides effective protection against unauthorized interference and ensures the security and privacy of video transmission.

We pride ourselves on our strong R&D team, composed of experts and engineers with rich experience and professional knowledge in the field. They are constantly exploring and innovating to bring forth new and improved products that stay ahead of the market trends.

Our manufacturing facilities are equipped with state-of-the-art machinery and adhere to international quality standards. This ensures that every product leaving our factory is of the highest quality and reliability.

Packing and Delivery

Selling Units:	Single item
Single package size:	20X10X5 cm
Single gross weight:	0.2kg
Package Type:	Each piece is individually packed into a bag and then packed into a carton.

Autel Anti Fpv C-Uas Mavic 3 Autel Fpv Ua Poland RF Module 700-1000MHz 50W GaN Anti-Module
